1325 cnc machine for aluminum plate
|Payment Type:||L/C,T/T,D/P,Paypal,Money Gram|
|Terms of Trade:||FOB,CIF,FCA|
|Min. Order:||1 Set/Sets|
|Delivery Time:||15 Days|
|Packaging:||Wooden case packing All Cnc Router are packed with standard inner plastic wrap and export wooden case.The inner layer is mainly wrapped with the wrapping film, and the carving machine is fixed, filled with EPE foam, and sealed by the standard export woode|
|Place of Origin:||China|
|Supply Ability:||200 Sets per month|
|Certificate:||ISO 9001 CE|
|Port:||Qingdao Port,Shanghai Port,Dalian Port|
Model No.: UT-1325
1325 cnc machine for Aluminum Plate
Service & Feedback
A. The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination.
B. We are responsible for offering the fittings free of charge during the guarantee period, while it is preferred you send the damaged fittings to us by courier with your charge for our testing, after confirming damage, we will send back the alternative fittings to you. After the guarantee of quality period, the parts required repairing or change, if any, shall be paid.
C. When you meet some complicated problem and online-support can not solve it, we can offer Door-Visiting Service. If our engineer to assemble or/and maintain or/and adjust the machine is/are required, we shall assist to deal with the visa formality and prepaid traveling expenses and accommodation to us during the business trip and the service period before their dispatch. And you can arrange for the translating person for the service engineer during their service period. Or you can send your engineer to China. We will offer long-term technical training to him for free.
SESAME Cnc Router's advantages:
1. Machine bed
Machine bed with 200 * 300mm square tube welded together, compared to ordinary machines, we use the square tube model can better reflect the stability of the equipment.
2. Reserved Position for Forklift
Bed welding process increases the reserved forklift, highlights two major advantages: First, increase the strength of the bed itself; Second, it`s more convenient for customers to load or unload the equipment.
3. Transmission stand column
Transmission stand column, we adopt high precision machining process, ensure the accuracy of accessories. Like insert cavity position, assembly surface.
4. SESAME machine head
First, For the choice of hand piece, we choose T6061/6063 aviation aluminum alloy as the base material. Through the precision processing of CNC Processing Center, we finished
our finished parts. Second, the high requirement assembly process ensures the precision of the product.
5. Hiwin/PMI square rail&High quality helical rack pinion
Sesame choose heavy duty linear guide rail with high assembly Flange sliding block and PMI linear guide. The Y-axis adopts double-row four-column guide rail, with strong bearing force, fast speed, smooth operation, high precision and high life span.
Rack of Sesame adopts high-precision 1.25 helical rack, which is complementary with the professional motor and professional deceleration device, which runs smoothly, high speed, high precision and low noise.
Working area: 1300*2500mm
Table Surface: Vacuum or T-slot
Frame: Square pipe welding bed structure
X, Y Structure: Gear and rack transmission, Taiwan PMI Linear Rail
Z Structure: Taiwan TBI Ball Screw, Taiwan PMI Linear Rail
Max. Rapid Travel Rate: 45000mm/min
Max. Working Speed: 25000mm/min
Spindle Power: 3.2kw/3.5kw(4.5kw, 5.5kw for option)
Spindle Speed: 0-24000RPM
Drive Motors: Stepper motor and driver
Working Voltage: Custom made
Operating System: Nc-studio (DSP or Mach3 optional)
Computer Interface: Ethernet (or USB)
Packaging & Shipping
1. Machine will be packed with wrapping film, EPE foam, and wooden case(composite material box/plywood case).
2. SESAME Cnc Router's machine legs and machine bed can be separated freely, when machine shipping, we'll dismantle the machine legs, then can help you save more shipping fee.
UTECH have Cnc Router Series, include Mini Desktop Cnc Router, Advertising Cnc Router, Woodworking Cnc Router, Professional Stone Cnc Router, Sign Cnc Router, ATC Cnc Router; Vision Localization/CCD Series include Cnc Router with CCD, Oscillating Knife Cutter with CCD.
If you're interested in this kind of machine, welcome to contact me.
Pls tell me,
1. Which kind of material you wanna process and cutting/engraving thickness?
2. How about your material's dimensions?
